• Easy installation, compact and compatible with any size drill

• Customized to each mine's specific drilling pattern

• Matrix indication results in correctly spaced and accurately placed holes.

• Allows drill operator fast, simple alignment with the center line

• Spalling of rock face does not result in the loss of portions of the indicated pattern

• Improved mine safety due to reduced human presence at the rock face

• Ability to lock Image position after pattern positioning

• Control of over-break resulting in consistent, improved haulage and reduced clearing time.

• Use on  declines or inclines of up to 15 degrees.

• Simple and easy to use. Requires only one hour of training for drill operator.
